Level Sensors & Switches

Fabri-Level Switch Kits

Part Number: 26130
Fabri-LevelKit_26675
Image is of similar product

PRODUCT DESCRIPTION:

Fabri-Level Switch Kits contain all components for complete assembly of a 1- or 2-station level switch unit for pipe-plug mounting in your tank. Kits are available in several material and size combinations. N.O. or N.C. operation of the SPST switch is selectable by inverting the float(s) on the unit stem. Two 10" (254 mm) lengths of tube are furnished to space level stations as desired.

LEAD TIME:

5 days
Lead-times and expedites

Lead-times apply to standard parts & configurations. Expedited shipments available by contacting factory. Lead-times may vary based on quantity and/or non-standard configurations.

CE ROHS Gems Compliant CSA

Features

  • 1 Tube Connector
  • 1 Mounting Plug
  • 2 Level Stations (Switch; Tube; Float)
  • 2 Extension Tubes
  • 1 Tube End Fitting
  • 3 Tube Unions
Sku
26130
Model
Fabri-Level
Sensor Type
Float Type
Primary Material Of Construction
Alloy
Wetted Materials
316 Stainless Steel, Buna N
Stem Material
Stainless Steel
Float Material
Buna N
Float Diameter
1 3/16"
Min. Liquid SG
0.75
Maximum Pressure
150 psi
Minimum Temperature
-40°F
Maximum Temperature
230°F
Mounting Size
1 1/4" MNPT
Electrical Termination
60" Long, 18 AWG, Teflon Leads
Switch Type
SPST (20 VA)
Switch Operation
Selectable
Approvals
ROHS

Gems Sensors Instructions, Fabri-Level Switch Kit

Format .pdf
Size 134 KB

Gems Sensors Catalog, Fabri-Level Kit

Format .pdf
Size 3 MB
