How Ultrasonic Sensors Can Be Used in Mining Equipment
February 27, 2019
In mining, mineral and metal processing technology is essential. This technology separates the valuable minerals from waste which is usually done so using magnets.
Challenge
Monitor water level in the dirty tank
In this mining application, ferrous minerals are being removed from a slurry via a magnetic wheel. The slurry is pumped into a tank in which the magnetic wheel is rotating vertical into the water/slurry mixture. The wheel picks up the ferrous particles suspended in the slurry and collects them on the surface of the wheel. As the portion of the wheel rotates out of the slurry, a mechanical edge scrapes the collected ferrous material off the wheel and into a bin. The customer needed to monitor the water level in the tank to ensure that the system would function properly.
Solution
UCL-510 Ultrasonic Continuous Level Sensor
Key Features
- Accurate monitoring of water/slurry level of processing tank
- High IP rating and robustness of housing
- Simple installation and signal/programming integration
- Non-contact measurement
Other Features
- 49-Inch (1245 mm) Range. 1" NPT Mounting
- Non-contact for corrosive, sticky or dirty applications
- Combines 4 relays, 4-20mA output and pump/valve control in one small sensor
